Multifunctional NPK Compound Fertilizer Production Line Pan Granulator

Pan Granulator With Organic Fertilizer Production Line

Working Principle :

Raw material ingredients: Urea, ammonium nitrate, ammonium chloride, ammonium sulphate, ammonium phosphate (monoammonium phosphate, diammonium phosphate, and coarse whiting, ca), potassium chloride, potassium sulfate and other raw materials are matched in proportion (according to the market demand and the around soil of test results).

Raw materials mixing: The mixture of the ingredients should be mixed to improve the uniform fertilizer efficiency of the granules.
Granulation of raw material: The raw material after mixing equably will be sent to granulator (drum granulator, and extruding granulator both can be used).

Granulation drying: put the granulation into the dryer, and the moisture in the granules will be dried, so that the granulation strength is increased and is easier to store.

Granulation cooling: After drying, the granulation’s temperature is too high and the granulation is easy to lump. While after cooling, it is easy to bagging to save and transport.

Particle classification: the cooling particles that have been cooled will be graded: the unqualified particles will be crushed and regranulated, and the qualified products will be sift out.

Finished film: The qualified products are coated to increase the brightness and roundness of granules.
Packaging of finished product: The particles that have been wrapped the film are stored in the ventilated place.

• [Productivity]: 1-20000 tons
• [Scope of aplication]: Organic / inorganic frtilizer production
• [pliable Materials] : Carbon-containing materials such as chicken manure, cattie manure dheep manure,pig manure and NPK fertilizer,compound or chemical fertilizer, mineral ferilizer. etc

major equipment in the fertilizer production line

Batching machine:The main machine is composed of feding system, weighing device,silo and conveyor belt.it has high automation and only needs manual feeding.it greatly saves time and production costs and meets the national measurement standards.

Grinder:Cage crusher is suitable for the crushing of bulk materials in compound fertilizer production, but also widely used in chemical industry, building materials, mining and other industries. In the crushing process, the machine adopts high-strength bran-resistant cemented carbide chain plate with synchronous rotating speed.The inlet and outlet ports are designed reasonably,the crushed materials are uniform,the wall is ont easy to stick,and it is easy to clean up.

Blender:High eficiency, high stirring sfficiency and less floor area.Helical blades are made of special alloy with high wear resistance, smooth operation is driven by reducer,smooth and low noise,reasonable structure of single-axle mixer feeding from tom top and discharging from bottom.

Granulator:adopts the whole circular arc structure, and the granulating rate can reach more than 93%.lt has three discharging ports,which is convenient for discomtinuous production,greatly reducing the labor intensity and improving the labor efficiency. the plate bottom is strengthened by a plurality of radiant steel plates,which is durable and never deformed.

Dryer:Rotary dryer is suitable for drying of organic frtilizer, slag clay limestone phosphogypsum steel plant,sludge of water slag power plant and sewage treatment Plant,it has the advantages of large drying capacity,stable operation,low energy consumption,convenient operation and high output.

automatic packing and Mechanical gripper:For handling or palletizing box-shaped materials, adjustable grabbing size, light aluminum alloy body, 304 stainless steel standard parts, swing hook base, one-way translation clamping ensures stable and reliable grabbing finished product.

All types of equipment are complete to meet the needs of customers. If you have special needs, please contact our engineers in order to tailor the most suitable production line for you. Welcome customers to consult.
