Anti Block Npk Fertilizer Production Line Npk Granulator Machine No Pollution

Product Details

Place of Origin: CHINA

Brand Name: GOFINE

Certification: CE

Model Number: 2x8

Payment & Shipping Terms

Minimum Order Quantity: 1 SET

Packaging Details: nude packing/carton/pallet packing/plywood box

Delivery Time: within 20 working days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 10 SETS / MONTH

Get Best Price
Product Details
Highlight:

npk fertilizer production plant

,

npk fertilizer production line

Key Word 1:
15 15 15 NPK Compound Fertilizer Granules Machine
Feature:
Gofine NPK Fertilizer Pellets Making Machine
Materials:
Carbon Steel Or SS
Capacity:
1-50 T/h
Input Moisture:
Less Than 10%
Temperature:
30-80 Degree
Output Water:
Less Than 3%
Name:
15 15 15 Npk Compound Fertilizer Granules Or Pellets Making Machine
Warranty:
24 Months
Installation:
Guide
Key Word 1:
15 15 15 NPK Compound Fertilizer Granules Machine
Feature:
Gofine NPK Fertilizer Pellets Making Machine
Materials:
Carbon Steel Or SS
Capacity:
1-50 T/h
Input Moisture:
Less Than 10%
Temperature:
30-80 Degree
Output Water:
Less Than 3%
Name:
15 15 15 Npk Compound Fertilizer Granules Or Pellets Making Machine
Warranty:
24 Months
Installation:
Guide
Product Description

Gofine 15 15 15 Npk Compound Fertilizer Granules Or Pellets Making Machine



Introduction of 15 15 15 Npk Compound Fertilizer Granules Or Pellets Making Machine

  • N : Urea, Di Ammonium Phosphate, Ammonium Chloride, Ammonium
  • Nitrate, Ammonium Sulphate, Mono Ammonium Phosphate Etc.
  • P as P2O5 : Single Super Phosphate , Triple Super Phosphate, D. A. P. etc..
  • Potash as K2O: Potassium Chloride, Potassium Sulphate etc.
  • Soil Conditioners & fillers : Gypsum, Sand and Dolomite etc.
  • Coating Agents: color agents and clay etc.
  • Bagging Material : Laminated HDPE bags

The calculated and measured quantities of the above mentioned raw materials is mixed properly in a mixer. The homogeneous mass is then processed in the drum granulating machine. The drum rotates at very low RPM. The material goes up and down with the cylinder for some height and then starts rolling again and again. As the material rolls on, the size of the granule increases. This material is transferred to the dryer with the help of a conveyor. The material is then passed through the cooler for cooling. Then transferred to screen to get diameter 1-4mm granules. The oversize and under-size are recycled back to the granulation process. Finally the end fertilizer is packed in 50 Kg bags.



Capacity or output of 15 15 15 Npk Compound Fertilizer Granules Or Pellets Making Machine

We can design the drawing and offer you capacity 10,000 ton per year to 300,000 ton per year according to your site. We send our technician to your side and have face to face confirm from A to Z, show you the complete NPK fertilizer production line.



Feature of 15 15 15 Npk Compound Fertilizer Granules Or Pellets Making Machine

Can be designed more automatically and advanced by Robots;

Can do different NPK ratio fertilizer from 20%-48%;

Anti-block and Uniform round granules with diameter 1-4mm;

Space tense occupied and smooth daily production;

No waste on materials and energy saved during operation;

Green and clean air and no pollution;



Equipment sheet of 15 15 15 Npk Compound Fertilizer Granules Or Pellets Making Machine

No. Processes Machines Function of machines
1 Batching process Automatic batching machine Ratio raw materials by formula
2 Grinding process Grinder Grind granules to powder
3 Mixing process Mixer Mix powder evenly, If necessary, add water, or other micro-elements
4 Granulating process Feeding machine Feed mixed powder into granulator evenly
Granulating equipment Make mixed powder into fertilizer granules
5 Drying process Dryer Dry fertilizer granules to low moisture by hot air
Hot stove Generate hot air to dryer
Cyclone Collect dust from dryer
6 Cooling process Cooler Cool fertilizer granules to normal temperature
Cyclone Collect dust from cooler
7 Screening process Screening machine Screen out required size from fertilizer granules
8 Coating process Coating machine Coat color, anti-blocking agent, micro-elements etc on fertilizer granules
9 Packaging process Air compressor Generate power to packaging machine
Packaging machine Package fertilizer granules into bags
