Product Details:
|
| Power: | 20-50kw | Feature: | NPK Compound Fertilizer Powder Supplier |
|---|---|---|---|
| Drawing: | 3-D Or Graphic Design For The Complete Production Line | Capacity: | 1-50 T/h |
| Input Moisture: | Less Than 30% | Temperature: | Room Temperature |
| High Light: | NPK Fertilizer Granules Making Machine,Organic Fertilizer Granules Making Machine,Compound Fertilizer Granules Making Machine |
||
Gofine NPK Organic fertilizer powder processing equipment supplier China
Introduction of Gofine NPK organic fertilizer powder processing equipment supplier China
The small-scale powder NPK organic fertilizer production line has low energy consumption, small floor space, no peculiar smell in the operating environment, zero pollution, good ventilation, and it only takes 1-2 days to deodorize. The small-scale organic fertilizer production line has a compact structure and advanced technology. It uses harmless living bacteria preparations to treat livestock and poultry manure, and conducts biological fermentation under the action of a variety of beneficial microorganisms. After fully decomposing the organic matter in it, nutrients are released, and the resulting biological heat and The high-temperature fermentation process can mie germs, insect eggs, detoxify and deodorize, purify the environment, achieve harmlessness, resource utilization and industrialization, with low energy consumption and stable product quality.
A small-scale organic fertilizer production line needs to build a fermentation tank, one machine with multiple tanks, and then the raw materials (dung, biogas residue, straw) are piled in the fermentation tank, and the fermentation bacteria of the biological organic fertilizer equipment are mixed in the raw material pile. 1 kg of decomposing agent can ferment 1 Tons of raw materials are mixed according to the comparison of raw materials. The fermentation cycle is 10-15 days when the temperature is around 0C°, and the fermentation period is once every 2 days, which can be completely decomposed. After being decomposed, it is crushed by an organic fertilizer pulverizer, and then sieved through a drum screen. The coarse material is sieved out and then fermented. The fine material can be granulated or directly bagged. The appearance of the particles is more beautiful and the granulation rate is higher.
Equipment sheet of Gofine NPK organic fertilizer powder processing equipment supplier China
| No. | Processes | Machines | Function of machines |
| 1 | Batching process | Automatic batching machine | Ratio raw materials by formula |
| 2 | Grinding process | Grinder | Grind granules to powder |
| 3 | Mixing process | Mixer | Mix powder evenly, If necessary, add water, or other micro-elements |
| 4 | Granulating process | Feeding machine | Feed mixed powder into granulator evenly |
| Granulating equipment | Make mixed powder into fertilizer granules | ||
| 5 | Drying process | Dryer | Dry fertilizer granules to low moisture by hot air |
| Hot stove | Generate hot air to dryer | ||
| Cyclone | Collect dust from dryer | ||
| 6 | Cooling process | Cooler | Cool fertilizer granules to normal temperature |
| Cyclone | Collect dust from cooler | ||
| 7 | Screening process | Screening machine | Screen out required size from fertilizer granules |
| 8 | Coating process | Coating machine | Coat color, anti-blocking agent, micro-elements etc on fertilizer granules |
| 9 | Packaging process | Air compressor | Generate power to packaging machine |
| Packaging machine | Package fertilizer granules into bags |
