110KW Cylindrical Organic Fertilizer Fermentation Equipment Carbon Steel Compost Tank

Cylindrical Organic Fertilizer Fermentation Equipment 24-30 M3/D

Fertilizer Fermentation Equipment characteristics

1.On-line CIP cleaning and SIP sterilization(121°C/0.1MPa);

2. According to the requirement of hygiene, the structure design is very humanized and easy to operate. The drive is stable and the noise is low.

3. Suitable ratio between diameter and height; according to the need to customize the mixing device,so the energy saving, stirring, the fermentation effect is good.

4. The inner tank has the surface polishing treatment (roughness Ra is less than 0.4 mm). Every outlet, mirror, manhole and so on.

Fertilizer Fermentation Equipment Parameters

Equipment Working Principle:

Intelligent thermo-aerobic treatment technology is to put the poultry and livestock manure into the fermentation tank. Then Oxygen is supplied to the manure through a scroll pump. Under the action of hydraulic mixing device and the gravity of the sludge itself, the manure falls layer by layer and is fermented once. The process lasts 7-12 days. The material is decomposed by aerobic fermentation. The heat released during the decomposition process can raise the temperature of the material itself, up to 80 C. The moisture of the material evaporates continuously during the fermentation process. Some organic matter is decomposed and decomposed, thus reducing the volume of the material and achieving the purpose of reducing and stabilizing the waste material.

The equipment of thermophilic aerobic fermentation tank is equipped with oxygen concentration sensor and temperature sensor. The oxygen delivery and temperature are automatically adjusted by PLC signal. Under the action of ventilation, oxygen filling and stirring, the fermentation temperature of materials is controlled between 55 and 65 degrees Celsius to reach the optimum temperature for material fermentation. At this temperature, a large number of pathogens and parasites in the stack can be killed and harmless. Purpose of treatment. Some of the treated materials are mixed with new materials as reflux materials, and most of them are sold as organic fertilizers after packaging to realize resource utilization. The odor produced during fermentation is discharged into deodorizer through collection system to avoid secondary pollution. The system is equipped with electrically assisted heating to ensure that fermentation conditions can be quickly reached at low temperature and continuous production can be ensured at low temperature.
