High Efficiency Drum Trommel Screen Machine Fertilizer Industry

High Efficiency Drum Trommel Screen Machine Fertilizer Industry
High Efficiency Drum Trommel Screen Machine Fertilizer Industry High Efficiency Drum Trommel Screen Machine Fertilizer Industry

Large Image :  High Efficiency Drum Trommel Screen Machine Fertilizer Industry

Product Details:
Place of Origin: Henan, China
Brand Name: Gofine
Certification: CE
Model Number: GS2.0X8
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negitionable
Packaging Details: plywood case
Delivery Time: 1-3Sets/15days
Payment Terms: L/C, Western Union, T/T, MoneyGram
Supply Ability: 25Sets/Month

High Efficiency Drum Trommel Screen Machine Fertilizer Industry

Description
Name: Trommel Screen Machine Application: Fertilizer Industry
Power: 15kw Working Speed: 12rpm
Capacity: 15-20T/H Feature: High Efficiency
High Light:

High Efficiency Trommel Screen Machine

,

Fertilizer Industry Trommel Screen Machine

,

Fertilizer Industry trommel drum Machine

High Efficiency Drum Trommel Screen Machine Fertilizer Industry



Working principle of Trommel Screen Machine



Trommel Screen Machine consists of motor, reducer, drum device, frame, sealing cover, inlet and outlet. The drum device is obliquely installed on the frame, and the motor is connected with the drum device through the reducer through the coupling to drive the drum device to rotate around its axis. When the material enters the drum device, due to the inclination and rotation of the drum device, the material on the screen surface turns over and rolls, so that the qualified material (products under the screen) is discharged through the cylindrical screen of the drum, and the unqualified material (products under the screen) is discharged The product is discharged through the end of the roller.



Introduction of Trommel Screen Machine



The trommel screening machine is common equipment in the production of compound fertilizer. It is mainly used for the separation of finished products and returned materials. It can also realize the classification of finished products, so that the finished products can be evenly classified.



Our screening machine can solve the issues such as blockage of the screening machine, low efficiency, wet materials, and high energy consumption. Cage trommel screening machine, because of its unique structural characteristics, completely and effectively solves the shortcomings of other types of screening equipment, and is the first choice for fertilizer production.



Trommel Screen Machine Parameters



model

Power

kw

Working speed rpm

Capacity

T/H

GS1X3 3 21 2-3
GS1.2X4 4 18 3-5
GS1.5X6 5.5 16 6-10
GS1.8X7 11 13 12-15
GS2.0X8 15 12 15-20



Pictures

High Efficiency Drum Trommel Screen Machine Fertilizer Industry 0

High Efficiency Drum Trommel Screen Machine Fertilizer Industry 1
