products

Home > products > Double Roller Fertilizer Granulator > 1 - 2mth Double Roller Granulator Double Screw Extruder 11 - 22kw Power

1 - 2mth Double Roller Granulator Double Screw Extruder 11 - 22kw Power

Name: 1 - 2mth Double Roller Granulator Double Screw Extruder 11 - 22kw Power
Brand: gofine
SKU: JZ-1T
Rating: 4.5 (141 reviews)

Product Details

Place of Origin: china

Brand Name: gofine

Certification: IOS9001/CE

Model Number: JZ-1T

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiation

Packaging Details: nude cargo

Delivery Time: 5-8work-days

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 30set/monthly

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                double roller fertilizer granulator, extrusion granulator


Application:	Fertilizer Granulation For Lab Use	Color:	Any
Capacity:	1000kg/h	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Power:	11-22kw	Materials Of Roller:	Alloy Steel

Application:	Fertilizer Granulation For Lab Use
Color:	Any
Capacity:	1000kg/h
After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Power:	11-22kw
Materials Of Roller:	Alloy Steel

Product Description

1-2MTH double screw extruder, lab twin screw extruding machine

Introduction

Powdery material(chemical/mineral/fertilizer) is fed into the hopper quantificational and uniformly through the feeder to make sure a certain level inside of the hopper. After being pre-compressed by the longitudinal cone spiral in the hopper the material will be sent into arc chutes of two rollers. Half-oblate arc chutes are uniform distributed on the surface of two rollers. Under the driving of a couple of gears, the two rollers rotate inversely with constant speed. As the volume decreases through the region of maximum pressure, the material is formed into a solid compact or sheet and fall into the grinding & classifying system. Products that meet requirements will be collected from the discharging port and the rest will return back to the hopper through recycle system.

Without any intermediates or additives, this machine can produce uniform and densified particle products directly from raw powdery material. The design of this roll compactor is reasonable, and easy to operate, it’s an idea choice for dry powder granulation.

The raw materials have wide adaptability and high granulation rate It can produce compound fertilizers of various comcentra ions and types

Product Details

Ball forming rete can reach 85%.no drying
Double roll pressure determines particle strength
Roll speed is adjusted by changing the belt pulley transmission ratio
Roll skin adopts new wear-resistant material

parameter

Model	power(kw)	Particle diameter(mm)	Roller size(mm)	Overall dimensions(mm)
JZ-1T	diameters4.5mm : 11 diameter > 4.5mm : 15	3- 10	150*220	14508001450
JZ-1.5T	diameters4.5mm : 18.5 diameter > 4.5mm : 22	3- 10	150*300	14508501500
JZ-2T	diameters4.5mm : 22 diameter > 4.5mm : 30	3- 10	185*300	16308501650
JZ-2.5T	diameters4.5mm: 37 diameter > 4.5mm : 45	3- 10	300*300	185011002050

1 - 2mth Double Roller Granulator Double Screw Extruder 11 - 22kw Power 0
